BluNODE
Modular Building Performance Monitor
from $1,000
Precision data logger for temperature, pulse, Modbus, and power monitoring. BluNODE captures high‑resolution data across 20 temperature sensors, 40 Modbus devices, 4 pulse inputs, and 4 current transformers—all in a single, industrial‑grade device. Deploy standalone or integrate with BluCORE for facility‑wide intelligence.
Not sure which BluNODE you need? Compare Models
Essential Monitoring. Expandable Performance.
BluNODE is the foundation of modular building performance monitoring. With support for 20 temperature sensors, 40 Modbus devices, 4 pulse inputs, and 4 current transformers, BluNODE handles the most common monitoring applications right out of the box.
Need more? Add the CL expansion board for 4‑20mA analog capability or the DP board for built‑in differential pressure sensors—BluNODE grows with your monitoring needs.
Key Benefits
Where BluNODE Excels
Temperature Monitoring Track temperature at up to 20 points—hot water delivery, HVAC performance, mixing valves, ambient conditions, and thermal systems.
Utility Monitoring via Pulse Meters Connect to pulse‑output water, gas, or electric meters for consumption tracking and submetering applications.
Power Monitoring with Current Transformers Monitor electrical consumption at the circuit or equipment level using the four built‑in CT inputs.
Modbus Integration Connect to up to 40 Modbus sensors and devices—integrate existing building automation equipment into your monitoring network.
Commissioning & Performance Verification Deploy for baseline studies, performance validation, or diagnostic projects using the comprehensive base sensor suite.
BluNODE delivers professional‑grade monitoring capability right out of the box—no expansion boards required for most applications.
20× Temperature Inputs
Thermistors, RTDs, or thermocouples for comprehensive thermal monitoring across your facility.
4× Pulse Inputs
Dry contact or reed switch pulse counting for water, gas, or electric meters.
4× Current Transformer Inputs
Monitor electrical consumption at the circuit or equipment level.
40× Modbus Sensors
RS‑485 Modbus RTU connectivity for existing sensors and building automation equipment.
Ten‑Year Battery Life
Designed for extended deployments with minimal maintenance—set it and forget it.
Technical Specifications
BluNODE Base Model
| Temperature Monitoring | |
| Temperature Inputs | Up to 20 temperature sensors |
| Sensor Types | Thermistors, RTDs, thermocouples |
| Accuracy | ±0.5°C (sensor dependent) |
| Pulse Monitoring | |
| Pulse Inputs | 4 pulse counter channels |
| Input Types | Dry contact, reed switch |
| Maximum Pulse Rate | Up to 100 pulses per second per channel |
| Power Monitoring | |
| CT Inputs | 4 current transformer channels |
| Measurement Range | 0-100A (CT dependent) |
| Applications | Circuit-level or equipment-level electrical monitoring |
| Modbus Integration | |
| Modbus Sensors | Up to 40 Modbus devices |
| Protocol | Modbus RTU over RS-485 |
| Baud Rate | 9600-115200 bps (configurable) |
| Network Connectivity | |
| Wireless Options |
|
| Wired Options | RS‑485, Ethernet (optional) |
| Network Integration | Standalone or integrated with BluCORE |
| Data Processing & Storage | |
| Processing | Local edge computing and data logging |
| Memory | Onboard storage for continuous data logging |
| Logging Interval | Configurable from 1 second to hourly (or longer) |
| Offline Operation | Fully functional without internet connection |
| Power | |
| Input Voltage | 12‑24VDC or 100‑220VAC (depending on model) |
| Power Consumption | Low‑power design for extended battery operation |
| Battery Life | Up to 10 years (in low‑power configurations) |
| Battery Type | Replaceable lithium or rechargeable options |
| Physical Specifications | |
| Enclosure | Industrial‑grade, ruggedized housing |
| Rating | NEMA 4X / IP65 (indoor/outdoor rated) |
| Mounting Options |
|
| Operating Temperature | ‑20°C to 60°C (‑4°F to 140°F) |
| Security | |
| Data Encryption | AES‑256 encryption for data transmission |
| Secure Communication | TLS/SSL encrypted wireless transmission |
| Local Storage | Encrypted local data storage |
| Software & Interface | |
| Configuration | Web‑based interface or BluCORE integration |
| Data Access | Local retrieval or remote access (when connected) |
| Alerts | Configurable thresholds and notifications |
| Export | CSV, Excel, API integration |
| Firmware Updates | Over‑the‑air (OTA) updates supported |
| Expansion Capability | |
| Expansion Boards |
|
| Installation | Customer‑installed or factory pre‑configured |
| Certifications & Compliance | |
| Standards | FCC, CE, UL certified |
| Environmental | RoHS compliant |
Two Ways to Add Capability
Option 1: Buy Pre‑Configured (Recommended)
Get BluNODE with expansion boards already installed—factory tested and ready to deploy.
BluNODE CL — Includes CL board pre‑installed for 4‑20mA analog sensors
BluNODE DP — Includes DP board pre‑installed with 4× differential pressure sensors
See BluNODE CL | See BluNODE DP
Option 2: Add Expansion Boards Later
Start with BluNODE base and add expansion boards when you need them—customer‑installed.
CL Expansion Board — Add 4‑20mA analog capability
DP Expansion Board — Add differential pressure sensors
Why Buy Pre‑Configured?
Same total price, pre‑installed and factory tested, no installation required, ready to deploy immediately.
Need Both Capabilities?
Combine any BluNODE model with expansion boards:
BluNODE CL + DP Board (analog + differential pressure)
BluNODE DP + CL Board (differential pressure + analog)
Talk to Our Team for help configuring your ideal setup.
Flexible. Scalable. Expandable.
Standalone Operation Deploy BluNODE as an independent data logger for targeted monitoring—zone‑level systems, individual equipment, or temporary studies.
Networked with BluCORE Connect multiple BluNODE devices to BluCORE for centralized data aggregation, analysis, and facility‑wide intelligence.
Integrated with BluPULSE Add BluPULSE pulse readers to extend your pulse metering capability beyond the four built‑in inputs.
Mixed Deployment Combine BluNODE base units with BluNODE CL and BluNODE DP devices across your facility to optimize costs and capabilities.
BluNODE Hardware
BluNODE precision data logger (base board)
Power supply and cables
Mounting hardware
Antenna (for wireless configurations)
Quick‑start guide
What’s Included
Software & Interface
Local data logging and storage
Integration with BluCORE dashboard (when networked)
Historical data access and export
Alert and notification capabilities
API access for custom integrations
Support Options
The Starter ($500) — Sensor selection and hardware design guidance
The Pro Setup ($100/mo) — Ongoing configuration and remote support
The Expert Edge ($250/mo) — Senior expert consultation for advanced deployments
Need Help Selecting Sensors?
BluNODE supports temperature, pulse, Modbus, and CT sensors right out of the box. Our support plans include expert guidance to help you select the right sensors and determine if you need expansion boards for your application.
BluNODE — from $1,000
Ready to Deploy?
Purchase a single BluNODE for immediate deployment, or request a quote for multiple units or facility‑wide monitoring systems.
Need 4‑20mA analog inputs for pressure or flow sensors?
Upgrade to BluNODE CL for precision analog capability.
Need differential pressure monitoring?
Upgrade to BluNODE DP for HVAC airflow diagnostics, filter monitoring, and commissioning applications.
Planning a larger deployment?
Our team can help you design the optimal mix of BluNODE, BluNODE CL, and BluNODE DP devices for your facility's monitoring needs.
Volume Pricing Available
Ordering multiple BluNODE devices or planning a campus‑wide deployment? Contact us for volume pricing and deployment consultation.
FAQs
What sensors does BluNODE support out of the box?
1
BluNODE includes 20 temperature inputs, 4 pulse inputs, 4 current transformer inputs, and 40 Modbus sensor connections—covering most building monitoring applications without expansion boards.
Can I add expansion boards later?
2
Yes! You can add the CL board (4‑20mA analog) or DP board (differential pressure) anytime—at purchase or in the field. Boards are customer‑installed with detailed instructions provided.
Can BluNODE operate without BluCORE?
5
Yes. BluNODE functions as a standalone data logger with local storage and processing. BluCORE integration is optional for centralized monitoring.
Can I move BluNODE between locations?
6
Absolutely. BluNODE's compact design and flexible mounting options make it ideal for temporary installations or redeployment as monitoring needs change.
Does BluNODE require an internet connection?
7
No. BluNODE operates independently with local data storage. Connectivity (Wi‑Fi, cellular, LoRaWAN) is optional for remote access and data transmission.
We offer three support plans—The Starter, The Pro Setup, and The Expert Edge—covering everything from initial setup to ongoing optimization.
What support is available after purchase?
8
Most applications work fine with the base BluNODE. Add CL if you need industrial 4‑20mA sensors (pressure transducers, flow meters). Add DP if you need HVAC differential pressure monitoring.
Do I need expansion boards?
3
Can I add both CL and DP boards?
4
Yes! BluNODE supports both expansion boards simultaneously for complete monitoring capability.
Ready to Add Modular Monitoring to Your Facility?
See how BluNODE can deliver flexible, expandable performance monitoring—start with what you need, add capability when you need it.
